Home » Products » Power Supply IC » Capacitor » MLCC THT capacitors » Capacitor: electrolytic / SNAP-IN / 100uF / 450VDC / Ø22x30mm / ±20% / LGN2W101MELZ30

Capacitor: electrolytic / SNAP-IN / 100uF / 450VDC / Ø22x30mm / ±20% / LGN2W101MELZ30

Capacitor: electrolytic / SNAP-IN / 100uF / 450VDC / Ø22x30mm / ±20% / LGN2W101MELZ30
Availability:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • LGN2W101MELZ30

  • Merry

Capacitor: electrolytic / SNAP-IN / 100uF / 450VDC / Ø22x30mm / ±20% / LGN2W101MELZ30

SPECIFICATION
Manufacturer : Merry
Type of capacitor : electrolytic
Mounting : SNAP-IN
Capacitance : 100µF
Operating voltage : 450V DC
Body dimensions : Ø22x30mm
Tolerance : ±20%
Service life : 3000h
Operating temperature : -25...105°C
Operating current : 0.69A
Leakage current : 0.63mA
Capacitors features : small sized body

LGN2W101MELZ30
