LSNC65R180GT
Product Name:
Lonten N-channel 650V, 20A, 0.18Ω LonFETTM Power MOSFET LSNC65R180GT DFN8×8
Product Description:
Description:
LonFETTM Power MOSFET is fabricated using
advanced super junction technology. The resulting
device has extremely low on resistance, making it
especially suitable for applications which require
superior power density and outstanding efficiency.
Features:
Ultra low RDS(on)
Ultra low gate charge (typ. Qg = 39nC)
100% UIS tested
RoHS compliant
Applications:
Power factor correction (PFC).
Switched mode power supplies (SMPS).
Uninterruptible power supply (UPS).
Product Summary:
VDS Tj,max: 700V
RDS(on),max: 0.18Ω
IDM: 60A
Qg,typ: 39nC
Introducing the Lonten N-channel 650V, 20A, 0.18Ω LonFETTM Power MOSFET LSNC65R180GT DFN8×8. This exceptional product is designed to minimize power loss and enhance overall efficiency, making it an ideal choice for various applications.
With its impressive 650V voltage rating and 20A current handling capacity, the LSNC65R180GT DFN8×8 Power MOSFET guarantees reliable performance even in demanding conditions. Its low on-resistance of 0.18Ω ensures efficient power transmission, enabling seamless operation and reducing energy wastage.
Crafted with precision and utilizing advanced technology, this N-channel Power MOSFET is engineered to deliver optimal results. Its compact DFN8×8 package allows for easy integration into existing systems, saving valuable space without compromising on performance.
Whether you're working on industrial equipment, power supplies, motor drives, or any other power-sensitive application, the Lonten LSNC65R180GT DFN8×8 Power MOSFET is your go-to solution. Trust in its superior quality, reliability, and exceptional performance to elevate your projects to new levels of efficiency.
Choose the Lonten N-channel 650V, 20A, 0.18Ω LonFETTM Power MOSFET LSNC65R180GT DFN8×8 and experience a reduction in power loss and an increase in overall efficiency. Elevate your power management capabilities with this professional-grade solution.
Product Specifications:
Product Name:
Lonten N-channel 650V, 20A, 0.18Ω LonFETTM Power MOSFET LSNC65R180GT DFN8×8
Product Description:
Description:
LonFETTM Power MOSFET is fabricated using
advanced super junction technology. The resulting
device has extremely low on resistance, making it
especially suitable for applications which require
superior power density and outstanding efficiency.
Features:
Ultra low RDS(on)
Ultra low gate charge (typ. Qg = 39nC)
100% UIS tested
RoHS compliant
Applications:
Power factor correction (PFC).
Switched mode power supplies (SMPS).
Uninterruptible power supply (UPS).
Product Summary:
VDS Tj,max: 700V
RDS(on),max: 0.18Ω
IDM: 60A
Qg,typ: 39nC
Introducing the Lonten N-channel 650V, 20A, 0.18Ω LonFETTM Power MOSFET LSNC65R180GT DFN8×8. This exceptional product is designed to minimize power loss and enhance overall efficiency, making it an ideal choice for various applications.
With its impressive 650V voltage rating and 20A current handling capacity, the LSNC65R180GT DFN8×8 Power MOSFET guarantees reliable performance even in demanding conditions. Its low on-resistance of 0.18Ω ensures efficient power transmission, enabling seamless operation and reducing energy wastage.
Crafted with precision and utilizing advanced technology, this N-channel Power MOSFET is engineered to deliver optimal results. Its compact DFN8×8 package allows for easy integration into existing systems, saving valuable space without compromising on performance.
Whether you're working on industrial equipment, power supplies, motor drives, or any other power-sensitive application, the Lonten LSNC65R180GT DFN8×8 Power MOSFET is your go-to solution. Trust in its superior quality, reliability, and exceptional performance to elevate your projects to new levels of efficiency.
Choose the Lonten N-channel 650V, 20A, 0.18Ω LonFETTM Power MOSFET LSNC65R180GT DFN8×8 and experience a reduction in power loss and an increase in overall efficiency. Elevate your power management capabilities with this professional-grade solution.
