Product Name:
1.0Amp Fast Recovery Silicon Rectifiers FR107 DO-41
Product Description:
FEATURES:
＊Low cost construction
＊Low reverse leakage
＊Fast switching for high efficiency
＊High forward surge current Capability
＊High Temperature soldering guaranteed:
260o C/10 seconds, 0.375”(9.5 mm) lead length at lbs (2.3kg) tension.
MECHANICAL DATA:
＊Case：Transfer Molded Plastic
＊Epoxy: UL94V-O rate flame retardant
＊Terminals：Plated axial lead, Solderable Per MIL-STD-202
Method 208
＊Polarity：Color band denotes cathode end
＊Mounting position: Any
＊Weight：0.012 ounce, 0.33 grams (approx)
＊In compliance with EU RoHs 2002/95/EC directives
The marking is indicated by part no. with “M”. ex: FR101M ~FR107M
Introducing the FR107 DO-41 Rectifier - your ultimate solution for efficient rectification.
Designed with utmost precision and reliability, the FR107 DO-41 Rectifier is a top-of-the-line product that guarantees exceptional performance in rectifying electrical currents.
With its compact DO-41 package, this rectifier offers easy installation and compatibility with various electronic circuits. Its robust construction ensures long-lasting durability, making it suitable for both commercial and industrial applications.
Equipped with cutting-edge rectifying technology, the FR107 DO-41 delivers optimal efficiency, allowing for seamless conversion of alternating current (AC) to direct current (DC). Whether you need to power up your electronic devices or regulate voltage levels, this rectifier is your go-to solution.
Rest assured, the FR107 DO-41 Rectifier adheres to the highest quality standards, ensuring stable and reliable performance even in demanding environments. Its professional-grade design guarantees smooth operation and minimizes the risk of electrical malfunctions.
Upgrade your rectification processes with the FR107 DO-41 Rectifier - the epitome of professionalism and efficiency in the world of rectifiers. Experience seamless power conversion like never before.
Product Specifications:
Product Name:
1.0Amp Fast Recovery Silicon Rectifiers FR107 DO-41
Product Description:
FEATURES:
＊Low cost construction
＊Low reverse leakage
＊Fast switching for high efficiency
＊High forward surge current Capability
＊High Temperature soldering guaranteed:
260o C/10 seconds, 0.375”(9.5 mm) lead length at lbs (2.3kg) tension.
MECHANICAL DATA:
＊Case：Transfer Molded Plastic
＊Epoxy: UL94V-O rate flame retardant
＊Terminals：Plated axial lead, Solderable Per MIL-STD-202
Method 208
＊Polarity：Color band denotes cathode end
＊Mounting position: Any
＊Weight：0.012 ounce, 0.33 grams (approx)
＊In compliance with EU RoHs 2002/95/EC directives
The marking is indicated by part no. with “M”. ex: FR101M ~FR107M
Introducing the FR107 DO-41 Rectifier - your ultimate solution for efficient rectification.
Designed with utmost precision and reliability, the FR107 DO-41 Rectifier is a top-of-the-line product that guarantees exceptional performance in rectifying electrical currents.
With its compact DO-41 package, this rectifier offers easy installation and compatibility with various electronic circuits. Its robust construction ensures long-lasting durability, making it suitable for both commercial and industrial applications.
Equipped with cutting-edge rectifying technology, the FR107 DO-41 delivers optimal efficiency, allowing for seamless conversion of alternating current (AC) to direct current (DC). Whether you need to power up your electronic devices or regulate voltage levels, this rectifier is your go-to solution.
Rest assured, the FR107 DO-41 Rectifier adheres to the highest quality standards, ensuring stable and reliable performance even in demanding environments. Its professional-grade design guarantees smooth operation and minimizes the risk of electrical malfunctions.
Upgrade your rectification processes with the FR107 DO-41 Rectifier - the epitome of professionalism and efficiency in the world of rectifiers. Experience seamless power conversion like never before.
Product Specifications:
